Beskrivelse

Service Portion Version (Diaphragm / Piston): Diaphragm
Spring portion Version (Diaphragm / Piston): Piston
Connection (Front cover / Intermediate flange):
Clamp Ring
Connection (Intermediate flange / Rear housing):
Bayonet
Radial port(s) orientation -
clockwise from mounting studs/hol:
0
Clamp ring ears orientation -
45
Service output at 6.5 bar &
30 mm stroke [kN]: 7.7
Spring portion output force at 30 mm stroke [kN]: 10.6
Mounting studs / holes centres [mm]: 120.7
Mounting studs length / holes depth [mm]: 33
Push rod thread length [mm]: 30
Front cover shape: Diamond
Function / description of release unit: Standard
Yoke type: Welded
Yoke pin diameter [mm]: 14H11
Yoke pin orientation -
clockwise from mounting studs/holes [°]: 0
Supplied with Port adaptors: No
Supplied with mounting nuts: Yes
Wading Ability: No
Gevindmål: M16x1,5
Slaglængde [mm]: 57 mm
Stempelstanglængde [mm]: 30 mm
Gevind, stempelstang: Yoke
Gevindmål 1: M16X1,5
Gevindmål 2: M16X1,5
Version: T20/30
Vægt [kg]: 9,2 kg
Brugsnumre: K153952N00, BX9466
