Beskrivelse

Service Portion Version (Diaphragm / Piston): Diaphragm
Spring portion Version (Diaphragm / Piston): Piston
Connection (Front cover / Intermediate flange):
Clamp Ring
Connection (Intermediate flange / Rear housing):
Bayonet
Radial port(s) orientation -
clockwise from mounting studs/hol:
90
Clamp ring ears orientation -
225
Service output at 6.5 bar &
30 mm stroke [kN]: 9.1
Spring portion output force at 30 mm stroke [kN]: 8.1
Mounting studs / holes centres [mm]: 120.7
Mounting studs length / holes depth [mm]: 43
Push rod protrusion [mm]: 15
Front cover shape: Diamond
Function / description of release unit: Standard
Supplied with Port adaptors: No
Supplied with mounting nuts: No
Wading Ability: No
Gevindmål: M16x1,5
Slaglængde [mm]: 57 mm
Gevindmål 1: M16x1,5
Gevindmål 2: M16x1,5
Version: T24/24
Vægt [kg]: 7,485 kg
Brugsnumre: II31408, BS9503
