Bremsecylinder/trykluftanlæg

Låsecylinder
For drejbar aksel

Bremsecylinder Kile
Stroke (stroke of service/stroke of spring portion) [mm] 53/53
Tube length (Measured to c/l of air port) [mm] 180 mm
Mounting tube end Flange
Weight [Kg] 10.21 kg
Service Portion Port(s) size M16x1,5
Service Portion Type (Diaphragm size) 16
Spring Portion Port(s) size M16x1,5
Spring Portion Type 20
Spring portion output force @ 25mm stroke [x100N] 90

Bremsecylinder
24/24
64/64 slaglængde

T24 lav

T30 lav

Gevindmål: M16x1,5
Slaglængde [mm]: 57 mm
Brugsnumre: K192161N00, BS7309

Låsecylinder for boogieaksel
BZ1614

T16 lav

Type: Knorr membrancylinder type 24 - BS2514
Benyttes til skivebremse på forvogn.
Diameter i typegodkendelsen:: -- mm.
Diameter udvendig på spændebånd: 189 mm.
Slaglængde: 64 mm.
Stempelstang: 15 mm.
Monteringsbolte afstand / gevind: 120, 7 mm. / m16x1, 5
Port: M22x1, 5

Additional description: T16/16
Service Portion Version (Diaphragm / Piston): Diaphragm
Spring portion Version (Diaphragm / Piston): Piston
Connection (Front cover / Intermediate flange):
Clamp Ring
Connection (Intermediate flange / Rear housing):
Bayonet
Radial port(s) orientation -
clockwise from mounting studs/hol:
90
Clamp ring ears orientation -
225
Service output at 6.5 bar &
30 mm stroke [kN]: 6.5
Spring portion output force at 30 mm stroke [kN]: 5.9
Mounting studs / holes centres [mm]: 120.7
Mounting studs length / holes depth [mm]: 43
Push rod protrusion [mm]: 15
Front cover shape: Diamond
Function / description of release unit: Standard
Supplied with Port adaptors: No
Supplied with mounting nuts: No
Wading Ability: No
Gevindmål: M16x1,5
Slaglængde [mm]: 57 mm
Gevindmål 1: M16x1,5
Gevindmål 2: M16x1,5
Vægt [kg]: 6,485 kg
Brugsnumre: II31227, BS9397

T12 lav

T9 lav

Håndbremsecylinder T61
1186754xu

Bremsecylinder
Type 12
Kilebremse
Slaglængde 50/50
