Bremsesystem

Title Extension: T24/24HFL3S
Service Portion Version (Diaphragm / Piston):
Diaphragm/Piston
Spring portion Version (Diaphragm / Piston): Piston
Connection (Front cover / Intermediate flange): Crimped
Connection (Intermediate flange / Rear housing):
Bayonet
Radial port(s) orientation -
clockwise from mounting studs/hol:
323
Clamp ring ears orientation -
0
Service output at 6.5 bar &
30 mm stroke [kN]: 9.1
Spring portion output force at 30 mm stroke [kN]: 10.9
Mounting studs / holes centres [mm]: 120.7
Mounting studs length / holes depth [mm]: 43
Push rod protrusion [mm]: 15
Front cover shape: Diamond
Function / description of release unit: Short
Supplied with Port adaptors: No
Supplied with mounting nuts: No
Opposite handed version: BK9509
Wading Ability: No
TÜV Test report: Y545268
Gevindmål: M16x1,5
Slaglængde [mm]: 64 mm
Gevindmål 1: VOSS232
Gevindmål 2: VOSS232
Version: Other
Brugsnumre: K235611N00, BK9502

T24. Til skivebremser
64mm slaglængde
KNORR
BS2504

T24. Til skivebremser
64mm slaglængde
KNORR
BS2504

Title Extension: T20/24HFL1
Service Portion Version (Diaphragm / Piston):
Diaphragm/Piston
Spring portion Version (Diaphragm / Piston): Piston
Connection (Front cover / Intermediate flange): Crimped
Connection (Intermediate flange / Rear housing):
Bayonet
Radial port(s) orientation -
clockwise from mounting studs/hol:
45
Clamp ring ears orientation -
0
Service output at 6.5 bar &
30 mm stroke [kN]: 7.3
Spring portion output force at 30 mm stroke [kN]: 9.4
Mounting studs / holes centres [mm]: 120.7
Mounting studs length / holes depth [mm]: 43
Push rod protrusion [mm]: 115
Front cover shape: Diamond
Function / description of release unit: Short
Supplied with Port adaptors: No
Supplied with mounting nuts: No
Opposite handed version: BK8414
Wading Ability: No
TÜV Test report: Y545268
Gevindmål: M16x1,5
Slaglængde [mm]: 64 mm
Gevindmål 1: M22x1,5N10164-NG12
Gevindmål 2: M22x1,5N10164-NG12
Version: Other
Brugsnumre: K281833N00, BK8413

Type: Knorr type 20/24 - BS9404
Benyttes til skivebremse på forvogn, anhænger og trailer.
Slaglængde: 64/64 mm.
Stempelstang: 15 mm.

EBS 2-kanalmodul Baghjul
Ny generation
EBS 5

EBS 2-kanalmodul Baghjul
Ny generation
EBS 5

EBS 2-kanalmodul Baghjul
Ny generation
EBS 5

BS3314
Type 16
57mm slaglængde
Integro chas.627
Travego chas.629

Bremsebakke med belægning SN3620

Type: Refako / Textar

Ombytter bremsebakke med Textar belægning.
Bremsestørrelse 360 x 200 mm.
Bremsebelægning - Textar: 511.907.00.033

Bremsecylinder forhjul skive T20
Voss gevind
BS3414

Type: Knorr-Bremse Fjederbremscylinder type 30/30 - BZ9657
Benyttes til tromlebremse på forvogn,
Slaglængde: 64 / 64 mm.
Stempelstang: M16x1,5
Monteringsbolte afstand / gevind: 120,7 mm. / m16x1,5
Port: M16x1,5 + M16x1,5
Membran: Type 30 - Stempel: Type 30 (98)
