Trykluftsystem

Title Extension: T12
Mounting tube end: 1-3/4" - 12 UNS
Tube length
(Measured to c/l of air port) [mm]: 186.5
Port(s) size: M16x1,5
Slaglængde [mm]: 44,5 mm
Vægt [kg]: 1,955 kg
Brugsnumre: I70694, BZ3221

Title Extension: T9
Mounting tube end: 1-3/4" - 12 UNS
Tube length
(Measured to c/l of air port) [mm]: 186.5
Port(s) size: M16x1,5
Slaglængde [mm]: 44,5 mm
Vægt [kg]: 1,84 kg
Brugsnumre: I66845, BZ3110

Title Extension: T12
Mounting tube internal diameter [mm]: 35
Mounting tube end: 1-3/4" - 12 UNS
Tube length
(Measured to c/l of air port) [mm]: 139
Port(s) size: M16x1,5
Slaglængde [mm]: 50 mm
Vægt [kg]: 1,88 kg
Brugsnumre: I67388, BZ3217

Air Inlet port(s) size: M22x1,5
Air Delivery port(s) size: M22x1,5
Limited delivery pressure [bar]: 3,5 +0,2
Safety valve pressure [bar]:
Without safety valve
Pressure range [bar]: 8,5
Maximum supply pressure: 12
Vægt [kg]: 0,52 kg
Brugsnumre: I61707, DB1116

Air Inlet port(s) size: M22x1,5
Air Delivery port(s) size: M22x1,5
Limited delivery pressure [bar]: 7,35+0,3
Safety valve pressure [bar]:
Without safety valve
Pressure range [bar]: 10
Maximum supply pressure: 12
Vægt [kg]: 0,54 kg
Brugsnumre: I61240, DB1113

Service Portion Version (Diaphragm / Piston):
Diaphragm/Piston
Spring portion Version (Diaphragm / Piston): Piston
Connection (Front cover / Intermediate flange):
Clamp Ring
Connection (Intermediate flange / Rear housing):
Bayonet
Radial port(s) orientation -
clockwise from mounting studs/hol:
0
Clamp ring ears orientation -
45
Service output at 6.5 bar &
30 mm stroke [kN]: 8.8
Spring portion output force at 30 mm stroke [kN]: 8
Mounting studs / holes centres [mm]: 120.7
Mounting studs length / holes depth [mm]: 43
Push rod protrusion [mm]: 15
Front cover shape: Diamond
Function / description of release unit: Standard
Supplied with Port adaptors: No
Supplied with mounting nuts: No
Wading Ability: No
Gevindmål: M16x1,5
Slaglængde [mm]: 64 mm
Gevindmål 1: M16X1,5N10172
Gevindmål 2: M16X1,5N10172
Version: T24/24
Vægt [kg]: 8,5 kg
Brugsnumre: K210352N00, BS6563

Title Extension: T12
Mounting tube end: 1-3/4" - 12 UNS
Tube length
(Measured to c/l of air port) [mm]: 186.5
Port(s) size: M16x1,5
Slaglængde [mm]: 44,5 mm
Vægt [kg]: 2,28 kg
Brugsnumre: I60838, BZ3214

Cover Colour: Black
Port(s) size: M22x1,5
Self sealing: No
With integrated Line Filter: No
Vægt [kg]: 0,18 kg
Brugsnumre: I59070, KU1303

Title Extension: T9
Mounting tube end: 1-3/4" - 12 UNS
Tube length
(Measured to c/l of air port) [mm]: 137.5
Port(s) size: M16x1,5
Slaglængde [mm]: 44,5 mm
Vægt [kg]: 1,71 kg
Brugsnumre: I58477, BZ3106

Air Inlet port(s) size: M22x1,5
Air Delivery port(s) size: M22x1,5
Vægt [kg]: 0,14 kg
Brugsnumre: I25351, AE5101

Air Inlet port(s) size: M22x1,5
Air Delivery port(s) size: M22x1,5
Vægt [kg]: 0,395 kg
Brugsnumre: I14911, AE4100

Title Extension: T9
Mounting tube internal diameter [mm]: 35
Mounting tube end: 1-3/4" UNF
Tube length
(Measured to c/l of air port) [mm]: 138
Port(s) size: M16x1,5
Slaglængde [mm]: 50 mm
Vægt [kg]: 1,715 kg
Brugsnumre: EF90AB
