Bus

Hurtigudløser
Type: Knorr-Bremse KX2552/3
Port 1: M22x1,5
Port 2: M16x1,5 (x2)
Port 3: M22x1,5

Hurtigudløser
Type: Knorr-Bremse KX2552/3
Port 1: M22x1,5
Port 2: M16x1,5 (x2)
Port 3: M22x1,5

Kompressor

Kompressor

Bremsekaliber

Type: Knorr K003811 SN7207RC

Monteringsside: Højre
Potentiometer med skruebefæstigelse
For Axial (vandret)monteret bremsecylinder

Alternativ: Meritor MXC9103154

Modsat side: K003812

Bremsekaliber

Type: Knorr K003812 SN7217RC

Træk- og boogieaksel
Knorr bremsesystem
Axial(vandret)monteret bremsecylinder

Alternativ: Meritor MXC9103153

Modsat side: K003811

Title Extension: T20/24HFL3S
Service Portion Version (Diaphragm / Piston):
Diaphragm/Piston
Spring portion Version (Diaphragm / Piston): Piston
Connection (Front cover / Intermediate flange): Crimped
Connection (Intermediate flange / Rear housing):
Bayonet
Radial port(s) orientation -
clockwise from mounting studs/hol:
45
Clamp ring ears orientation -
0
Service output at 6.5 bar &
30 mm stroke [kN]: 7.2
Spring portion output force at 30 mm stroke [kN]: 11
Mounting studs / holes centres [mm]: 120.7
Mounting studs length / holes depth [mm]: 43
Push rod protrusion [mm]: 15
Front cover shape: Diamond
Function / description of release unit: Short
Supplied with Port adaptors: No
Supplied with mounting nuts: No
Opposite handed version: BK8426
Wading Ability: No
TÜV Test report: Y545268
Gevindmål: M16x1,5
Slaglængde [mm]: 64 mm
Gevindmål 1: M22x1,5N10164-NG12
Gevindmål 2: M22x1,5N10164-NG12
Version: Other
Brugsnumre: K281836N00, BK8427

Title Extension: T20/24HFL3S
Service Portion Version (Diaphragm / Piston):
Diaphragm/Piston
Spring portion Version (Diaphragm / Piston): Piston
Connection (Front cover / Intermediate flange): Crimped
Connection (Intermediate flange / Rear housing):
Bayonet
Radial port(s) orientation -
clockwise from mounting studs/hol:
315
Clamp ring ears orientation -
0
Service output at 6.5 bar &
30 mm stroke [kN]: 7.3
Spring portion output force at 30 mm stroke [kN]: 11
Mounting studs / holes centres [mm]: 120.7
Mounting studs length / holes depth [mm]: 43
Push rod protrusion [mm]: 15
Front cover shape: Diamond
Function / description of release unit: Short
Supplied with Port adaptors: No
Supplied with mounting nuts: No
Opposite handed version: BK8427
Wading Ability: No
TÜV Test report: Y545268
Gevindmål: M16x1,5
Slaglængde [mm]: 64 mm
Gevindmål 1: M22x1,5N10164-NG12
Gevindmål 2: M22x1,5N10164-NG12
Version: Other
Brugsnumre: K281835N00, BK8426

ELC ventilblok

ELC ventilblok

ELC ventilblok

Air Inlet port(s) size: M10x1,0
Air Delivery port(s) size: M10x1,0
Cut-out pressure [bar]: 7,9 +/-0,2
Cut-in pressure [bar]: 7,1 +/-0,2
Pressure control range [bar]: 0,8 +/-0,2
Vægt [kg]: 0,43 kg
Brugsnumre: 1189393000, D-2
