Bremsecylinder m/ håndbremse

Varenummer:

402.K004052N00

Kombibremsecylinder IAM Preferred Part

Trækhjul 24/24
Slaglængde 64/64
BS9502/9509
Voss 232 gevind

Varenummer:

402.K028253N00

Fjederakkumulatorbremsecylinder IAM Preferred Part

Håndbremsecylinder T50

Varenummer:

2001235665

Kombibremsecylinder IAM Preferred Part

Title Extension: T20/24HFL3S
Service Portion Version (Diaphragm / Piston):
Diaphragm/Piston
Spring portion Version (Diaphragm / Piston): Piston
Connection (Front cover / Intermediate flange): Crimped
Connection (Intermediate flange / Rear housing):
Bayonet
Radial port(s) orientation -
clockwise from mounting studs/hol:
45
Clamp ring ears orientation -
0
Service output at 6.5 bar &
30 mm stroke [kN]: 7.2
Spring portion output force at 30 mm stroke [kN]: 11
Mounting studs / holes centres [mm]: 120.7
Mounting studs length / holes depth [mm]: 43
Push rod protrusion [mm]: 15
Front cover shape: Diamond
Function / description of release unit: Short
Supplied with Port adaptors: No
Supplied with mounting nuts: No
Opposite handed version: BK8426
Wading Ability: No
TÜV Test report: Y545268
Gevindmål: M16x1,5
Slaglængde [mm]: 64 mm
Gevindmål 1: M22x1,5N10164-NG12
Gevindmål 2: M22x1,5N10164-NG12
Version: Other
Brugsnumre: K281836N00, BK8427

Varenummer:

402.II18224

Kombibremsecylinder IAM Preferred Part

Type: Knorr-Bremse Fjederbremscylinder 16/16 - BS9398
Benyttes til skivebremse på forvogn, anhænger og trailer.
Slaglængde: 57/57 mm.
Stempelstang: 15 mm.
Monteringsbolte afstand / gevind: 120, 7 mm. / m16x1, 5
Port: M16x1, 5 + M16x1, 5
