Trykluftsystem

Port 1 - Air Supply Interface: M16x1,5
Port 4 - Hydraulic Control Interface: M14x1,5
Booster Diameter [mm]: 100,0
Total stroke: 70
Stroke Sensor: No
Control fluid: Brake Fluid
Wear Indicator: No
Wading Ability: No
Vægt [kg]: 2,842 kg
Brugsnumre: K127074N50, VG3610

Port 1 - Air Supply Interface: M16x1,5
Port 4 - Hydraulic Control Interface: M14x1,5
Booster Diameter [mm]: 100,0
Total stroke: 85
Stroke Sensor: No
Control fluid: Brake Fluid
Wear Indicator: Yes
Wading Ability: No
Vægt [kg]: 2,988 kg
Brugsnumre: K127075N50, VG3611

Port(s) size: M16x1,5
Vægt [kg]: 0,03 kg
Brugsnumre: SEB00253, ZB1218

Port 1 - Air Supply Interface: M16x1,5
Port 4 - Hydraulic Control Interface: M14x1,5
Booster Diameter [mm]: 100,0
Total stroke: 85
Stroke Sensor: No
Control fluid: Brake Fluid
Wear Indicator: Yes
Wading Ability: No
Vægt [kg]: 3,14 kg
Brugsnumre: K120572N50, VG3602

Port 1 - Air Supply Interface: M16x1,5
Port 4 - Hydraulic Control Interface: M14x1,5
Booster Diameter [mm]: 100,0
Total stroke: 85
Stroke Sensor: No
Control fluid: Brake Fluid
Wear Indicator: No
Wading Ability: No
Vægt [kg]: 3,021 kg
Brugsnumre: K120571N50, VG3601

Service Portion Version (Diaphragm / Piston): Diaphragm
Spring portion Version (Diaphragm / Piston): Piston
Connection (Front cover / Intermediate flange):
Clamp Ring
Connection (Intermediate flange / Rear housing):
Bayonet
Radial port(s) orientation -
clockwise from mounting studs/hol:
0
Clamp ring ears orientation -
270
Service output at 6.5 bar &
30 mm stroke [kN]: 11.4
Spring portion output force at 30 mm stroke [kN]: 11
Mounting studs / holes centres [mm]: 120.7
Mounting studs length / holes depth [mm]: 38
Push rod thread length [mm]: 251
Front cover shape: Diamond
Function / description of release unit: Standard
Yoke type: Without
Yoke pin orientation -
clockwise from mounting studs/holes [°]: 0
Supplied with Port adaptors: No
Supplied with mounting nuts: Yes
Wading Ability: No
Gevindmål: M16x1,5
Slaglængde [mm]: 64 mm
Stempelstanglængde [mm]: 251 mm
Gevind, stempelstang: M16x1,5
Gevindmål 1: M16X1,5
Gevindmål 2: M16X1,5
Version: T30/30
Vægt [kg]: 10,9 kg
Brugsnumre: K108671N00, BZ9666

Title Extension: T12
Mounting tube internal diameter [mm]: 35
Mounting tube end: 1,75" - 12 UNS
Tube length
(Measured to c/l of air port) [mm]: 160
Vægt [kg]: 6,166 kg
Brugsnumre: K003868000, BY9237

Title Extension: T12
Mounting tube internal diameter [mm]: 35
Mounting tube end: 1,75" UNS
Tube length
(Measured to c/l of air port) [mm]: 187
Vægt [kg]: 5,995 kg
Brugsnumre: K003845000, BY9233

Title Extension: T24
Push rod thread length [mm]: 300
Yoke pin diameter [mm]: 14
Stempelstanglængde [mm]: 300 mm
Vægt [kg]: 9,6 kg
Brugsnumre: K002609, BX9553

Title Extension: T24
Additional description: OBC
Version (Diaphragm / Piston): Diaphragm
Connection (Front / Rear cover): Crimped
Axial port(s) thread size: M16x1.5
Axial port(s) plugged: No
Radial port(s) thread size: M16x1.5
Radial port(s) plugged: No
Radial port(s) orientation -
clockwise from mounting studs/hol:
0
Service output at 6.5 bar &
30 mm stroke [kN]: 9.05
Mounting studs / holes centres [mm]: 120.7
Mounting studs length / holes depth [mm]: 43
Push rod protrusion [mm]: 15
Front cover shape: Diamond
Supplied with mounting nuts: No
Wading Ability: No
TÜV Test report: No
Gevindmål: M16x1,5
Slaglængde [mm]: 64 mm
Version: T24
Vægt [kg]: 3,515 kg
Brugsnumre: K002420, BS3532

Air Inlet port(s) size: Ø6 mm
Air Delivery port(s) size: Ø6 mm
Air Signal port(s) size: Not included
Height limitation port(s) size: Not included
Datum adjustment [deg.]: Not included
Height limitation [deg.]: Not included
Flow characteristic number: P1
Lever style: Flat
Lever length [mm]: 161
Mounting position: Right
Length without lever: 221
Vægt [kg]: 0,13 kg
Brugsnumre: K000661, SV1491

Air Inlet port(s) size: M22x1,5
Air Delivery port(s) size: M22x1,5
Backflow: without
Vægt [kg]: 0,261 kg
Brugsnumre: K000651, DR4385
