Trykluftsystem

Service Portion Version (Diaphragm / Piston): Diaphragm
Spring portion Version (Diaphragm / Piston): Piston
Connection (Front cover / Intermediate flange):
Clamp Ring
Connection (Intermediate flange / Rear housing):
Bayonet
Radial port(s) orientation -
clockwise from mounting studs/hol:
0
Clamp ring ears orientation -
90
Service output at 6.5 bar &
30 mm stroke [kN]: 8.5
Spring portion output force at 30 mm stroke [kN]: 8.3
Mounting studs / holes centres [mm]: 120.7
Mounting studs length / holes depth [mm]: 43
Push rod thread length [mm]: 237
Front cover shape: Diamond
Function / description of release unit: Standard
Yoke type: Without
Yoke pin orientation -
clockwise from mounting studs/holes [°]: 0
Supplied with Port adaptors: No
Supplied with mounting nuts: Yes
Wading Ability: No
Gevindmål: M16x1,5
Slaglængde [mm]: 64 mm
Stempelstanglængde [mm]: 237 mm
Gevind, stempelstang: 5/8"-18UNF
Gevindmål 1: 3/8NPTF-1
Gevindmål 2: 3/8NPTF-1
Version: T24/24
Vægt [kg]: 8,5 kg
Brugsnumre: K162818N00, BX9546

Connector: Snap-on Connector
Vægt [kg]: 0,05 kg
Brugsnumre: SIL68ASP

Service Portion Version (Diaphragm / Piston): Diaphragm
Spring portion Version (Diaphragm / Piston): Piston
Connection (Front cover / Intermediate flange):
Clamp Ring
Connection (Intermediate flange / Rear housing):
Bayonet
Radial port(s) orientation -
clockwise from mounting studs/hol:
0
Clamp ring ears orientation -
210
Service output at 6.5 bar &
30 mm stroke [kN]: 11.4
Spring portion output force at 30 mm stroke [kN]: 10.4
Mounting studs / holes centres [mm]: 120.7
Mounting studs length / holes depth [mm]: 43
Push rod thread length [mm]: 45
Front cover shape: Diamond
Function / description of release unit: Standard
Yoke type: Without
Yoke pin orientation -
clockwise from mounting studs/holes [°]: 0
Supplied with Port adaptors: No
Supplied with mounting nuts: Yes
Wading Ability: No
Gevindmål: M16x1,5
Slaglængde [mm]: 64 mm
Stempelstanglængde [mm]: 45 mm
Gevind, stempelstang: 5/8"-18UNF
Gevindmål 1: M16X1,5
Gevindmål 2: M16X1,5
Version: Other
Vægt [kg]: 9 kg
Brugsnumre: K162827N00, BZ9692

Cartridge connection type: M39x1,5 right hand thread
Cartridge type: OSC
Maximum Operating Pressure [Bar]: 14
Højde [mm]: 165 mm
Vægt [kg]: 2,4 kg
Brugsnumre: K039454, K039454X00

Air Inlet port(s) size: M16x1,5
Air Delivery port(s) size: M16x1,5
Maximum delivery pressure [bar]: 8.5
With Microswitch: No
With Test position: Yes
With Emergency Release feature: No
Exhaust Connector: M16x1,5
Ports position: Side facing
Number of inverse circuits: 1
Mounting flange: Hexagonal flange
Unlocking actuation: Pull Ring
Vægt [kg]: 0,835 kg
Brugsnumre: K038804N00, DPM23AK

Service Portion Version (Diaphragm / Piston): Diaphragm
Spring portion Version (Diaphragm / Piston): Piston
Connection (Front cover / Intermediate flange):
Clamp Ring
Connection (Intermediate flange / Rear housing):
Bayonet
Radial port(s) orientation -
clockwise from mounting studs/hol:
0
Clamp ring ears orientation -
90
Spring portion output force at 30 mm stroke [kN]: 800
Push rod thread length [mm]: 250
Front cover shape:
Diamond Almond Cross Diamond Almond Cross Diamond
Function / description of release unit: Standard
Supplied with Port adaptors: No
Supplied with mounting nuts: No
Opposite handed version: NO ENTRY
Slaglængde [mm]: 64 mm
Gevind, stempelstang: M16x1,5
Gevindmål 1: M16X150
Gevindmål 2: M16X150
Vægt [kg]: 8,5 kg
Brugsnumre: K162773N00, BZ9691

Vægt [kg]: 0,12 kg
Brugsnumre: SEB22280

Air Inlet port(s) size: M16x1,5
Air Delivery port(s) size: M16x1,5
Maximum delivery pressure [bar]: 8.5
With Microswitch: No
With Test position: Yes
With Emergency Release feature: No
Exhaust Connector: M16x1,5
Ports position: Side facing
Number of upright circuits: 1
Number of inverse circuits: 2
Mounting flange: Hexagonal flange
Unlocking actuation: Pull Ring
Vægt [kg]: 0,855 kg
Brugsnumre: K038803N00, DPM22AK

Air Inlet port(s) size: M22x1,5
Air Delivery port(s) size: M22x1,5
Purge control: Reservoir; Port: M12x1,5
Safety valve pressure [bar]: 13,0
With internal Silencer: No
Exhaust Connector: Snap-on Connector
Exhaust Silencer fitted: No
Heater Connector Type: Heater not included
Cartridge type: Conventional
Cartridge connection type: M39x1,5 right hand thread
Vægt [kg]: 3,82 kg
Brugsnumre: K024718, LA8703

Air Inlet port(s) size: VOSS NG12 M22x1,5
Air Delivery port(s) size: VOSS NG12 M22x1,5
Purge control: Reservoir; Port: Voss NG8 M16x1,5
Safety valve pressure [bar]:
Without safety valve
With internal Silencer: No
Exhaust Connector: Ø 20,0 mm
Exhaust Silencer fitted: No
Heater Connector Type: Heater not included
Cartridge type: Conventional
Cartridge connection type: M39x1,5 right hand thread
Vægt [kg]: 3,445 kg
Brugsnumre: K023357, LA8702

Title Extension: T20/24HF
Additional description: + mounting kit II37099
Service Portion Version (Diaphragm / Piston): Diaphragm
Spring portion Version (Diaphragm / Piston): Piston
Connection (Front cover / Intermediate flange):
Clamp Ring
Connection (Intermediate flange / Rear housing):
Bayonet
Radial port(s) orientation -
clockwise from mounting studs/hol:
0
Clamp ring ears orientation -
45
Service output at 6.5 bar &
30 mm stroke [kN]: 7.8
Spring portion output force at 30 mm stroke [kN]: 8.2
Mounting studs / holes centres [mm]: 120.7
Mounting studs length / holes depth [mm]: 38
Push rod thread length [mm]: 300
Front cover shape: Diamond
Function / description of release unit: Standard
Wading Ability: No
Gevindmål: M16x1,5
Slaglængde [mm]: 57 mm
Gevind, stempelstang: M16x1,5
Gevindmål 1: N10164
Gevindmål 2: N10164
Vægt [kg]: 8,315 kg
Brugsnumre: II37275, BX9401

Title Extension: T24
Push rod length
(to yoke pin centre if fitted) [mm]: 190
Push rod thread length [mm]: 180
Slaglængde [mm]: 75 mm
Gevindmål 1: M16x1,5
Vægt [kg]: 3,62 kg
Brugsnumre: II33442A, BX3535
